OEM 215mm 8 Inch Micro Bubble Generator For Waste Water Treatment With EPDM Membrane
-
Highlight
OEM micro bubble generator
,215mm micro bubble generator
,8 Inch micro bubble generator
-
Product NameFine Bubble Diffuser
-
ModelQRZ-BQPS
-
ApplicationWaste Water Treatment, Sewage Treatment, A/O Biochemical Process
-
MOQ10set
-
Size215(8"); 260(9"); 300(12")
-
Membrane MaterialEPDM Membrane
-
Support Plate And RingPP /ABS /UPVC As Required
-
Upper & Lower SaddlePP
-
Air Inlet Pipe4-1/2" (O.D.)
-
OEMAvailable
-
PortQingdao, Shanghai, Tianjin, Or Nearest Airport
-
Place of OriginHenan, China
-
Brand NameQRZ
-
Model NumberQRZ-BQPS
-
Minimum Order Quantity10 pieces
-
Price$11.00/pieces 10-98 pieces
-
Packaging DetailsPaper box
-
Supply Ability20000 Set/Sets per Month
OEM 215mm 8 Inch Micro Bubble Generator For Waste Water Treatment With EPDM Membrane
Fine bubble diffuser is used in aeration tank. It is used to transfer oxygen in large quantities. In contrast with the coarse bubble diffuser, this product allows more oxygen delivery in smaller bubbles than the larger ones. Further, the diffusers allow you to monitor and maintain the flow of air into the water.
|
Model |
QRZ-BQPS200 |
QRZ-BQPS260 |
QRZ-BQPS300 |
|
Size |
φ215mm (8 inch) |
φ260mm (9 inch) |
Φ300mm (12 inch) |
|
Working Air Flow |
1.5~3 m³/h |
2~5 m³/h |
2~8 m³/h |
|
Design Air Flow |
1.8 m³/h |
3.0 m³/h |
4.2 m³/h |
|
Bubble Size |
1~2mm |
1~2mm |
1~2mm |
|
Service Area |
0.3~0.65 m³/h |
0.4~0.8 m³/h |
0.5~1.0 m³/h |
|
O2 Utilization Rate |
22~30% |
22~30% |
22~30% |
|
Oxygenate Capacity |
0.13~0.4kgO2/h |
0.21~0.4kgO2/h |
0.21~0.53kgO2/h |
|
Submerged Depth |
4~8m |
4~8m |
4~8m |
|
Pressure Drop |
<3000Pa |
<3000Pa |
<3000Pa |
|
Membrane Material |
EPDM /Low Memory EPDM / Silicone Rubber |
||
|
Base Plate Material |
ABS |
ABS |
ABS |
|
Saddle |
PP |
PP |
PP |
|
Connection |
3/4” NPT male thread |
3/4” NPT male thread |
3/4” NPT male thread |
Our products are sold all over the world, you can rest assured.
